Drying room evaporator overview The drying chamber evaporator is the key equipment in the drying chamber, which uses the principle of evaporation to transfer heat to the items to be dried, so as to achieve the effect of rapid drying. Function The working principle of the evaporator in the drying...

Send Inquiry

Description

Drying room evaporator

overview

The drying chamber evaporator is the key equipment in the drying chamber, which uses the principle of evaporation to transfer heat to the items to be dried, so as to achieve the effect of rapid drying.

Function

The working principle of the evaporator in the drying chamber is based on the evaporation process of the liquid, that is, the physical phenomenon that the liquid is converted into a gas under certain conditions.

Working principle

In the drying room, the evaporator is usually combined with a heating system, which evaporates the liquid (such as refrigerant or water) in the evaporator by heating, and absorbs heat from the surrounding air. This heat is then transferred to the item to be dried, so that the water on its surface evaporates and exits the drying chamber, thus achieving the purpose of drying.

Specification	Tube pitchA	Row pitchB	Tube size	Tube Material	Fin pitch	Fin Material
*φ7mm2118.2*	21mm	18.2mm	φ7mm	Copper Tube(SmoothTubeor Rifled Tube)	2.0-4.5mm adjustable	Aluminumfin(Bare finorhydrophilicfin)
*φ12mm3530.31*	35mm	30.31mm	φ12mm	Copper Tube(SmoothTubeor Rifled Tube)	4.0-10mm adjustable	Aluminumfin(Bare finorhydrophilicfin)
*φ15mm6030*	60mm	30mm	φ15mm	Copper Tube(SmoothTubeor Rifled Tube)	4.0-10mm adjustable	Aluminumfin(Bare finorhydrophilicfin)

Structure

Drying chamber evaporator is usually composed of heating chamber, evaporation chamber, condenser, pipe system and control system.

The heating chamber provides heat to heat up and evaporate the liquid in the evaporator; The evaporation chamber is the main place where the liquid evaporates and absorbs heat; The condenser is used to condense the evaporated gas into a liquid for recycling. The piping system is responsible for the transfer and distribution of heat and steam in the drying chamber; The control system is used to monitor and adjust the temperature and humidity in the drying room.
