Parallel Flow A/C Evaporator

parallel flow AC evaporator is a type of evaporator used in automotive air conditioning systems. It consists of a series of tubes or passages through which refrigerant flows parallel to the airflow. As the warm air from the cabin passes over the evaporator, the refrigerant absorbs the heat and turns into a gas, cooling the air in the process. The cool air is then distributed back into the cabin through the air vents.

The parallel flow design of the evaporator allows for more efficient heat transfer, resulting in faster cooling times and improved energy efficiency compared to other types of evaporators. It also allows for a smaller, more compact design, making it ideal for use in vehicles where space is limited.

Overall, the parallel flow AC evaporator plays a crucial role in maintaining a comfortable temperature inside a vehicle, especially during hot summer months.

Parallel Flow A/C evaporator Production process

1. Design and Engineering: The first step in the production process of a Parallel Flow AC Evaporator is to design and engineer the component. This involves determining the dimensions, materials, and specifications required for the evaporator to function effectively.

2. Material Selection and Procurement: The next step is to select the appropriate materials for the evaporator and procure them from suppliers. This includes selecting the tubes, fins, headers, and other necessary components.

3. Tube Bending and Assembly: The tubes are then bent to the required shape and size and the fins are attached to them. The headers are also assembled to the tubes.

4. Cleaning and Quality Control: The assembled evaporator is then cleaned to remove any impurities and inspected for quality control purposes.

5. Welding: Welding is then carried out to join the tubes and headers together.

6. Brazing: After welding, the evaporator is brazed to seal the joints and ensure that it is leak-proof.

7. Pressure Testing: The evaporator is then pressure tested to ensure that it can withstand the required pressure for efficient operation.

8. Painting and Finishing: Finally, the evaporator is painted and finished to give it the desired appearance and protect it from corrosion.

9. Packaging: The finished evaporator is then packaged and prepared for shipping to the customer.

Products display:

Product superiority

Factory actual shoot

Service process

Packaging transportation
