Air Conditioner Fin Condenser

Air conditioner Fin Condenser



Fin Condenser are vital components in thermal management systems, known for their ability to enhance heat transfer efficiency through the use of extended surfaces called fins. These fins increase the contact area between fluids and the exchanger surface, making them ideal for applications where one medium-often air-has low thermal conductivity. From HVAC systems and industrial refrigeration to automotive radiators and aerospace cooling units, fin heat exchangers are engineered to deliver reliable performance while optimizing space, weight, and energy consumption.



1. Material: copper, aluminum, galvanized plate.
2. Copper pipe: diameterΦ7, Φ7.94, Φ9.52, inner grooved or smooth tube.
3. Aluminum foil: hydrophilic or bare
4. Fin type: louver fin, flat fin, corrugated fin
5. Pitch of fins: Ø7 1.1~1.8mm Ø7.94 1.4~2.0 mm Ø9.52 1.4~2.3 mm
6. Pitch of holes and pitch of rows: 20.5x12.7mm, 22x19.05mm, 21x12.7mm, 25.4x22mm equilateral triangle arrangement.

We make tubes of different diameters, with a greater number of thicknesses and different materials such as copper,stainless steel and cupronickel. The tube expansion, during the flaring phase, allows a perfect contact between the tubesand the fins and as a consequence it assures efficient thermal exchange.



Our Products









Company profile



We are a professional heat exchanger, condenser, evaporator manufacturer in China.Our products have been exported to Europe, Brazil, Middle east, Japan, etc.



By choosing us, you are choosing professional, reliable and quality service.
